Vormax

VorMax® Plus Two-Piece 1.0 gpf/3.8 Lpf Chair Height Right-Hand Trip Lever Elongated Toilet With Seat

The VorMax Plus 1.0gpf/3.8Lpf Chair Height Elongated Toilet from American Standard infuses LYSOL® toilet bowl cleaner into the water with each flush, freshening the bowl day after day. VorMax technology has been proven to clean the bowl 2X better than a regular toilet, thanks to a unique flushing system that produces a powerful jetted scrub. CleanCurve rim eliminates hidden, hard to reach areas where dirt and buildup can collect. Our EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria. Backed by a lifetime warranty on chinaware, this ultra high-efficiency toilet uses just 1 gallon per flush and is WaterSense® certified for its water-conserving design and performance. Easy to install, it features an elongated bowl and 17-in. height to ensure comfort and accessibility.

White 238AA115CP.020 DISCONTINUED
List Price: $0.00
ADA Compliant CEC Certified Everclean Water Efficient WaterSense
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • POWERFUL FLUSH - Patented flush technology sends twice as much jetted water to the rim
  • ULTRA-HIGH EFFICIENCY - UHET uses 1.0 gallons per flush to conserve water
  • FRESHNESS IN EVERY FLUSH - Specially formulated FreshInfuser releases the cleaning power of LYSOL® and lasts up to 30 days
  • BUILT-IN FRESHINFUSER COMPARTMENT – Seamlessly hidden and easy to access
  • FRESHINFUSERS INCLUDED – Two VorMax Plus FreshInfuser packs are included with purchase
  • Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria on the toilet
  • RIGHT-HAND TRIP LEVER - Chrome-plated finish
  • 12-INCH ROUGH-IN
  • WARRANTY — Lifetime warranty of chinaware, 10 years on mechanical parts, 1 year on seat
  • CHAIR-HEIGHT COMFORT — Measures 17” tall, including seat, for ease of use compared to standard height. Slight variation in height may occur based on the height of the seat used.\n,ADA COMPLIANT — Meets Americans with Disabilities Act requirements for use and accessibility\n,DURABLE CONSTRUCTION — Made from quality vitreous china for strength and reliability
Technical Features
  • Automatic self-cleaning VorMax® toilet bowl that freshens the bowl with every flush
  • The specially formulated VorMax® Plus FreshInfuser® features the cleaning power of LYSOL* and lasts up to 30 days†
  • The VorMax® jetted scrub plus the cleaning power of LYSOL* work together to keep the bowl clean and smelling fresh
  • Two VorMax® Plus FreshInfuser® packs included with purchase of toilet
  • Cleaning compartment is seamlessly hidden and easy to access
  • Slow-close, quick release seat included for easy cleaning
  • VorMax® flushing technology cleans two times better than conventional toilets‡
  • Combination bowl with seat plus tank
  • 12" (305 mm) rough-in;Chair Height elongated siphon action bowl;Meets EPA WaterSense® and MaP Premium criteria
  • Trip lever on right-hand side
Nominal Dimensions: 30-3/16 in x 17-7/8 in x 32-1/4 in (767 mm x 454 mm x 819 mm)
Description
Net Weight
SKU
Color
List Price USD
VorMax® Plus Two-Piece 1.0 gpf/3.8 Lpf Chair Height Right-Hand Trip Lever Elongated Toilet With Seat
1 lb (0.4 kg)
238AA115CP.020 *
White (020)
0
Separate Components
Vormax Elongated Toilet Bowl with Vormax Plus Seat and Two FreshInfusers
61 lb (27.7 kg)
3385A100CP.020 *
White
377
spacer
VorMax® 1.0 gpf/3.8 Lpf 12-Inch Rough Right-Hand Trip Lever Tank Only
36 lb (16.5 kg)
4385A115.020
White
269
spacer
VorMax® 12-Inch Rough Toilet Tank Cover
8 lb (3.6 kg)
735216-400.020
White
121
Spare Parts
Right-Hand Trip Lever
0 lb (0.1 kg)
7381799-200.0020A
Chrome
101


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Front to Back Length: 16-1/2
Bowl Shape: Elongated
Brand: American Standard
Category: Toilets
CEC Certified: Yes
Chair Height: Chair
Color / Finish: White
Collections: Vormax
WaterSense: Yes
Everclean: Yes
Fixture Material: Vitreous China
Fixture or Fitting Material: Vitreous China
Flush Technology: Gravity Fed
Flush Valve Size: 2.063
Flusing Type: Single Flush
Gallons Per Flush (min-max): 1.0 GPF
MAP Performance Rating: 1000
Height: 32-1/4
Length: 30-3/16
Length: 30-3/16
Width: 17-7/8
Residential or Commercial: Residential
Rough In Size: 12
Subcategory: Floor Standing Toilets
Trip Lever Location: Left Front
Toilet Water Efficiency: Hight Efficiency Toilet
Toilet Mount Type: Floor Mount
Toilet Seat Type: Closed
Seat Included: Yes
Toilet Type: Two Piece
Warranty: 10 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
3D Objects are not currently available for this product
