Features
- TRADE EXCLUSIVE TANK
- 12-INCH ROUGH-IN
- WATERSENSE® CERTIFIED — Uses 20 percent less water and performs as well as or better than regular toilets
- POWERWASH® RIM — Scrubs the bowl clean with every flush
- FINISHING TOUCHES — Includes color-matched bowl caps and trip lever
- METAL PARTS — Robust metal trip lever and metal shank fill valve
- DURABLE CONSTRUCTION — Made from quality vitreous china for strength and reliability
- LESS SEAT - Toilet seat is sold separately
Technical Features
- Includes tank, bowl, and installation kit (seat not included)
- Bowl Shape: Round-Front
- Rim Height: Normal Height measuring 15.5" (with seat) rim height
- Rough-In: 12" (305 mm)
- Configuration: Two-piece exposed trapway design
- Flush Rate: 1.60 gpf (6Lpf) single flush low-consumption toilet
- Made with durable metal components including metal trip lever, arm and brass shank
- Metal trip-lever, chrome
- Trapway: 2-1/8" (54 mm) fully glazed
- PowerWash® Rim Design,EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria,Limited Lifetime Warranty, see warranty page on website for detail
Nominal Dimensions: 28-1/4 in x 17-1/4 in x 28-7/8 in (718 mm x 438 mm x 733 mm)
Cadet® PRO Two-Piece 1.6 gpf/6.0 Lpf Standard Height Round Front Toilet Less Seat
1 lb (0.4 kg)
Bone (021)
609
White (020)
354
Linen (222)
609
Cadet® PRO Standard Height Round Front Bowl
47 lb (21.3 kg)
White
192
Bone
306
spacer
Cadet® PRO 1.6 gpf/6.0 Lpf 12-Inch Rough Tank
28 lb (12.6 kg)
White
162
Bone
303
spacer
Cadet® PRO 1.6 gpf/6.0 Lpf 12-Inch Rough Lined Tank
28 lb (12.6 kg)
White
263
spacer
Cadet® PRO 12-Inch Rough Toilet Tank Cover
7 lb (3.3 kg)
White
102
Bone
129
spacer
Left-Hand Trip Lever
0 lb (0.2 kg)
Brushed Cool Sunrise
86
Cardiff Slow-Close Round Front Toilet Seat
3 lb (1.4 kg)
White
77
Bone
85
Left-Hand Trip Lever
0 lb (0.2 kg)
Chrome
54
Polished Nickel
65
Polished Brass
56
Oil Rubbed Bronze
94
Matte Black
81
Legacy Bronze
129
Brushed Nickel
76
Cadet® PRO Two-Piece 1.6 gpf/6.0 Lpf Standard Height Round Front Toilet Less Seat
1 lb (0.4 kg)
Bone (021)
609
White (020)
354
Linen (222)
609
Cadet® PRO Standard Height Round Front Bowl
47 lb (21.3 kg)
White
192
Bone
306
spacer
Cadet® PRO 1.6 gpf/6.0 Lpf 12-Inch Rough Tank
28 lb (12.6 kg)
White
162
Bone
303
spacer
Cadet® PRO 1.6 gpf/6.0 Lpf 12-Inch Rough Lined Tank
28 lb (12.6 kg)
White
263
spacer
Cadet® PRO 12-Inch Rough Toilet Tank Cover
7 lb (3.3 kg)
White
102
Bone
129
spacer
Left-Hand Trip Lever
0 lb (0.2 kg)
Brushed Cool Sunrise
86
Cardiff Slow-Close Round Front Toilet Seat
3 lb (1.4 kg)
White
77
Bone
85
Left-Hand Trip Lever
0 lb (0.2 kg)
Chrome
54
Polished Nickel
65
Polished Brass
56
Oil Rubbed Bronze
94
Matte Black
81
Legacy Bronze
129
Brushed Nickel
76
Models marked with * are discontinued, but product may still be available while supplies last.
