Retro-Fit™

25" Shower System

26487EN0 DISCONTINUED
List Price: $0.00
Enjoy More Rewards LIXIL Select
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • GROHE LongLife finish
  • GROHE DreamSpray
  • GROHE Speed Clean
  • Wall mounted diverter shower system
  • 12 3 /16" Optional fixed or swivel standard shower arm
  • Switch between hand shower and shower head or dual function via built-in diverter
  • Adjustable height bar with gliding element
  • Supply elbow connection
  • 59" Metal shower hose (26 994)
  • Includes flow-restrictor + click valve at inlet,Available to be purchased separately,Wall spacer for upper bracket (26 030) and,shower system 6" height extension (26 464)
Technical Features
  • GROHE LongLife finish
  • Wall mounted diverter shower system
  • 12 3/16" Optional fixed or swivel standard shower arm
  • Switch between hand shower and shower head or dual function via built-in diverter
  • 6 diverter functions (2 discrete functions (non shared) + one shared function in both standard and Eco flow)
  • Adjustable height bar with gliding element
  • Distance between diverter and upper bracket 25 3/4" (653 mm)
  • Angle adapter to prevent hose interfering with shower valve
  • System includes 2 back flow preventers
  • 59" Metal shower hose (26 994),Optional 1.75gpm (6.6L/min) flow restrictor included,Showerhead and hand shower (not included),CALGreen Compliant,Optional: Wall spacer for upper bracket (26 030) (sold separately),Optional: Shower system 6" height extension (26 464) (sold separately)
Description
Net Weight
SKU
Color
List Price USD
"Retro-Fit 25" Shower System"
11 lb (4.8 kg)
26487EN0
0
26487000
0
Spare Parts
Non-Return Valve
0 lb (0.0 kg)
08565000
0
spacer
Holder for Sliding Rail
2 lb (1.0 kg)
12140EN0
0
spacer
"Retro-Fit Spacer"
1 lb (0.3 kg)
26030000
0
spacer
"Retro-Fit 6” Height Extension"
1 lb (0.5 kg)
26464000
0
spacer
Diverter
0 lb (0.2 kg)
48058000
0
spacer
Flow Rate Limiter
0 lb (0.0 kg)
48160000
0
spacer
Non-Return Valves
0 lb (0.0 kg)
48184000
0
Download Specification Sheet
Brand: GROHE
Category: Shower Systems Retrofits, Slide Bar Kit
Color / Finish: Brushed Nickel (GEN)
Collections: Retro-Fit™
Fitting Connection Size Input: 12.70
Input Connection Type: NPT (National Pipe Tapered Threads)
Kitchen or Bathroom: Bath
LIXIL Select: Yes
Height: 32-9/16
Length: 10-1/4
Residential or Commercial: Residential
Corrosion Resistance: Yes
Shower Bar Length: 635.00
Subcategory: Diverter Shower System bare
Warranty: Limited Lifetime Warranty
