Features
- Flush Plug: Eliminates the need to remove cartridge during installation and allows installer to flush the lines without cross flow. Can be tested using flush plug with air (200 psi) or water (300 psi).
- Stainless Steel Retaining Ring with Flats: Secures test cap/ cartridge in place and eliminates need for screws. Flats make it simple to loosen ring for quick, easy insertion/removal of test cap/cartridge.
- Flat Back: Allows valve to be mounted flush against cross brace for easy and solid installation
- PEX Connections: Fast and easy installation without adaptors reducing leak points.
- Cast DZR Brass Valve Body: Resists corrosion due to high chloride and pH levels in water.
- Back-to-Back Capability: Hot and cold can be reversed quickly and easily.
- Exclusive Plaster Guard: Plaster guard is designed to protect valve and act as a guide during installation. It can serve as mounting support for thin-wall installations.
- Wide Rough-in Range: From 1-3/4" to 2-3/4" from finished wall to the back of the valve.
- 1/2" PEX crimp inlets/Universal outlets (ASTM F1807)
- Includes Scredriver Stops for easy servicing at the valve,Cartridge Ships with Trim
Technical Features
- 1/2" (13 mm) PEX crimp inlets/Universal outlets (ASTM F1807)
- Cast DZR brass valve body
- Flow rate: 5.1 gpm @ 45 psi*
- Back-to-back capability
- Includes flush plug with stainless steel ring
- Includes screwdriver stops for easy servicing at the valve
- Cartridge ships with trim
- For use with TU series pressure balance bath/shower trim kits
Nominal Dimensions: 2-3/4 in x 4-7/8 in x 3-5/8 in (70 mm x 124 mm x 92 mm)
Flash® Shower Rough-In Valve With PEX Inlets/Universal Outlets With Screwdriver Stops for Crimp Ring System
2 lb (0.8 kg)
No Finish (007)
115
PBV DEEP ROUGH-IN KIT
0 lb (0.0 kg)
Platinum Nickel
50
Satin Brass
50
spacer
Test Cap Assembly
0 lb (0.0 kg)
No Finish
6
spacer
Retaining Ring
0 lb (0.1 kg)
No Finish
13
spacer
Flush Plug Assembly
0 lb (0.0 kg)
No Finish
13
Flash® Shower Rough-In Valve With PEX Inlets/Universal Outlets With Screwdriver Stops for Crimp Ring System
2 lb (0.8 kg)
No Finish (007)
115
PBV DEEP ROUGH-IN KIT
0 lb (0.0 kg)
Platinum Nickel
50
Satin Brass
50
spacer
Test Cap Assembly
0 lb (0.0 kg)
No Finish
6
spacer
Retaining Ring
0 lb (0.1 kg)
No Finish
13
spacer
Flush Plug Assembly
0 lb (0.0 kg)
No Finish
13
Models marked with * are discontinued, but product may still be available while supplies last.
