Features
- Brass Casting: Highest quality faucet material for durability & long life.
- Wax Thermostatic Unit: Permits shuttle valve to move between the hot and cold seats to maintain the pre-selected constant water temperature.
- Back to Back Capable: Hot and cold can be reversed.
- Spring-Loaded Check Valves: When the hot and cold water enters the fitting, both supplies pass through the spring-loaded check valves to prevent cross flow of hot and cold water. Integrated stop valves ensure easy cleaning and servicing.
- Adjustable Hot Limit Safety Stop: Limits the amount of hot water allowed to mix with cold. Reduces the risk of accidental scalding. Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit.
- Ideal with multiple shower outlets
- <lt/>i<gt/>MUST order with ON/OFF Volume Control to complete system<lt/>/I<gt/>
Technical Features
- 3/4" (19 mm) NPT inlets/outlets
- 16 gpm/60.6 L/min at 40 psi
- All Ceratherm valves are thermostatically controlled to maintain a constant shower temperature even in cases of water supply pressure and temperature changes; adjustable temperature selections
- Hot Limit Safety Stop set to a maximum of 112°F (44°C) with interim stops for local conditions
- Meets ASSE Standard 1016 – Type T
- Must order with On/Off volume control to complete system
- When used as a bath/shower a separate diverter valve is required (R422, R422S, R433, R433S or diverter tub spout)
- Requires twin ell for use with diverter tub spout
There are no additional components to display for this product
Brand:
American Standard
Category:
Rough-ins Concealed Bodies
Color / Finish:
No Finish
Collections:
Roughs/Valves
Fitting Connection Size Input:
19.05
Fitting Material:
Brass
Mount Type:
Wall Mount
Fixture or Fitting Material:
Brass
Input Connection Type:
NPT (National Pipe Tapered Threads)
Number of Input Valves:
2
Number of Output Valves:
2
Output Connection Type:
NPT (National Pipe Tapered Threads)
Height:
3.375
Length:
3-5/8
Residential or Commercial:
Residential
Subcategory:
Thermostat Valve Rough in
Valve Input Diameter:
3/4
Valve Output Diameter:
3/4
