2-Handle Thermo Rough Valve W/Built-In-2

This thermostat allows you to shower at a pre-selected water temperature and choose between two separate shower outlets. An adjustable hot limit safety stop helps reduce the risk of accidental scalding. Features high quality brass casting for durability and long life.\nBuilt-in diverter allows the user to choose between 2 and 3 separate outlets. Wax Thermostatic unit maintains the pre-selected constant water temperature. Back to Back Capable: hot and cold can be reversed. Spring-loaded Check valves prevents the cross flow of hot and cold water. Integrated stop valves ensure easy cleaning and servicing.\nAdjustable hot limit safety stop reduces the risk of accidental scalding. Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit. Compatible with Town Square Shower Trim Kit, Serin Shower Trim Kit, Green Tea Shower Trim Kit, Times Square Shower Trim Kit, Moments Shower Trim Kit, Berwick Shower Trim Kit, Portsmouth Shower Trim Kit, Quentin Shower Trim Kit

Features
  • High quality brass casting for durability and long life
  • Built-in diverter allows the user to choose between 2 and 3 separate outlets
  • Wax Thermostatic unit maintains the pre-selected constant water temperature
  • Back to Back Capable: hot and cold can be reversed
  • Spring-loaded Check valves prevents the cross flow of hot and cold water
  • Integrated stop valves ensure easy cleaning and servicing
  • Adjustable hot limit safety stop reduces the risk of accidental scalding
  • Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit
  • 104 or 109 degrees Fahrenheit.
Technical Features
  • High quality brass casting for durability and long life
  • Built-in diverter allows the user to choose between 2 and 3 separate outlets
  • Wax Thermostatic unit maintains the pre-selected constant water temperature
  • Back to Back Capable: hot and cold can be reversed
  • Spring-loaded Check valves prevents the cross flow of hot and cold water
  • Integrated stop valves ensure easy cleaning and servicing
  • Adjustable hot limit safety stop reduces the risk of accidental scalding
  • Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit
  • 104 or 109 degrees Fahrenheit.
Description
Net Weight
SKU
Color
List Price USD
2-Handle Thermo Rough Valve W/Built-In-2
6 lb (2.9 kg)
No Finish (007)
346
Substitutions
Flash® 2-Way Integrated Shower Diverter Rough-In Valve with Pressure Balance Valve Cartridge
4 lb (1.8 kg)
No Finish
355


Models marked with * are discontinued, but product may still be available while supplies last.
Brand: American Standard
Category: Rough-ins Concealed Bodies
CEC Certified: Yes
Color / Finish: No Finish
Collections: Roughs/Valves
Fitting Connection Size Input: 0-1/2
Fitting Material: Brass
Mount Type: Wall Mount
Fixture or Fitting Material: Brass
Input Connection Type: NPT (National Pipe Tapered Threads)
Number of Input Valves: 2
Number of Output Valves: 3
Output Connection Type: NPT (National Pipe Tapered Threads)
Height: 9.25
Length: 3-5/8
Residential or Commercial: Residential
Subcategory: Thermostat Valve Rough in
There are no design files currently available for this product
There are no videos currently available for this product
3D Objects are not currently available for this product
