Madera

Madera 15-Inch EverClean® Toilet System With Touchless Selectronic® Piston Flush Valve, 1.0 gpf/3.8 Lpf

The Madera Floor-Mount Toilet System from American Standard features the 1.0 gpf/3.8 Lpf Ultima Selectronic flush valve that uses minimal water to clear the bowl with maximum efficiency. The self-cleaning piston flush valve design saves time and money by reducing routine maintenance and preventing the valve from running due to clogs.

White 3451665.020 DISCONTINUED
List Price: $796.00
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Exclusive self-cleaning valve technology: DynaClean® integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Manual override assurance: Fully mechanical override button for operation without power
  • Fail-safe operation: Valve automatically closes upon loss of power or water pressure
  • Resists dezincification: Made of proprietary brass alloy
  • 5-year CR-P2 lithium battery installed in valve to eliminate downtime and the need for constant replacement
  • Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria
  • Powerful flush: Direct-fed siphon jet flush action
  • Standard bowl height: 15" (381 mm) rim height
  • Fully glazed trapway: 2-1/8" (54 mm); 2" (51 mm) minimum ballpass
  • Inlet spud: 1-1/2" (38 mm),Rough-in: Available in 10" (254 mm) or 12" (305 mm)
Technical Features
  • Maximum 800 gram MaP Score
  • Elongated floor mount flushometer bowl, top spud, less seat
  • 15" (381 mm) rim height
  • EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
  • Touchless piston-operated flush valve
  • 5-year CR-P2 lithium battery installed in valve
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
Description
Net Weight
SKU
Color
List Price USD
Madera 15-Inch EverClean® Toilet System With Touchless Selectronic® Piston Flush Valve, 1.0 gpf/3.8 Lpf
1 lb (0.4 kg)
3451665.020
White (020)
796
Separate Components
Madera 1.0 - 1.6 gpf (3.8 - 6.0 Lpf) 15" Height Top Spud Elongated EverClean® Bowl
50 lb (22.8 kg)
3451001.020
White
214
spacer
Ultima Selectronic Touchless Toilet Flush Valve, Piston-Type, Battery, 1.0 gpf/3.8 Lpf
7 lb (3.0 kg)
6065100.002
Chrome
582
Brand: American Standard
Category: Flush Valves and Sanitary Items
Color / Finish: White
Collections: Madera
Gallons Per Flush (min-max): 1.0 GPF
Residential or Commercial: Commercial
Subcategory: Sensor Flush Valve and Sanitary Items
Warranty: 5 Year Limited Warranty
There are no supporting files currently available for this product
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
There are no design files currently available for this product
There are no videos currently available for this product
3D Objects are not currently available for this product
