2-In-1 Integral Touchless Faucet/Soap Dispenser, Base Model

The sleek 2-In-1 Integral Touchless Faucet/Soap Dispenser from American Standard is an innovative solution for hygienic, hands-free hand-washing that helps to reduce the spread of germs with its contactless convenience. This unique integrated combination features two infrared sensors: one to dispense water and another to dispense a rich, foam soap. Clean, contemporary design is ideal for new projects and a smart, easy update for retrofit applications, from the industry’s most trusted name in bathroom fittings.

Chrome 776B112.002 DISCONTINUED
List Price: $885.00
ADA Compliant Cal Green CEC Certified Water Efficient WaterSense
Items REQUIRED for Install
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Flexible single post design can be installed on sinks with single-hole (CHO) or 4" centerset. Deck plate sold separately.
  • Two separate infrared sensors
  • To activate, place hand near sensor on side of spout to dispense soap; place hand under front of spout to dispense water
  • Rectangular 1.2 gpm pressure-compensating, vandal-resistant aerator
  • Brass spout and shank
  • Below deck soap and air pump
  • Adjustable foam volume (4 levels)
  • Uses any brand of foam soap that meets viscosity requirements of 1-20 cps; no proprietary soaps needed
  • Includes 1.8L soap bottle with quick release button
  • Base model uses existing American Standard AC power kits, sold separately,Optional 4-inch deck plate, sold separately, for easy installation on sink with 4" centerset
Technical Features
  • Base model uses the existing American Standard Plug-In or Hard-Wired AC power kits (sold separately)
  • Stylish spout dispenses foam soap and water for a hygienic hand wash
  • Touchless operation limits the spread of germs
  • Uses universal bulk foam soap; no proprietary soaps needed
  • Air infused foam soap generator with 4 adjustable foam volume settings
  • Includes 1,800 ml soap bottle with quick disconnect
  • Vandal-resistant brass spout with single-hole installation
  • Vandal-resistant 1.2 gpm/4.5 Lpm rectangular aerator
  • Optional deck plate for 4" (102 mm) centers available
Description
Net Weight
SKU
Color
List Price USD
2-In-1 Integral Touchless Faucet/Soap Dispenser, Base Model
4 lb (1.8 kg)
776B112.002
Chrome (002)
885
Required Components (Not Included)
Selectronic® Hard Wired AC Power Kit
1 lb (0.3 kg)
PK01.HAC
No Finish
140
spacer
Selectronic® Plug-In AC Power Kit
1 lb (0.4 kg)
PK01.PAC
No Finish
109
Optional Components (Not Included)
4-Inch Deck Plate
0 lb (0.1 kg)
7353101P.002
Chrome
54
Spare Parts
Aerator Kit
0 lb (0.0 kg)
M970741-0070A
No Finish
23
spacer
Spout Kit
2 lb (1.0 kg)
M970742-0020A
Chrome
361
spacer
Air and Soap Pump Assembly
1 lb (0.5 kg)
M970743-0070A
No Finish
298
spacer
Solenoid Box with Inlet Hose
1 lb (0.3 kg)
M970744-0070A
No Finish
134
spacer
Battery Housing Box
0 lb (0.2 kg)
M970745-0070A
No Finish
38
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Cal Green: Yes
Category: Commercial Fittings
CEC Certified: Yes
Color / Finish: Chrome
Department of Energy Certified: Yes
Collections: Selectronic
WaterSense: Yes
Fitting Material: Brass
Spout Type: High Arc
Touchless: Touchless
Fixture or Fitting Material: Brass
Gallons Per Minute (min-max): 1.2 GPM
Hardware Included: Yes
Height: 8-11/16
Width: 1-9/16
Residential or Commercial: Commercial
Subcategory: Sensor Commercial Fittings
Warranty: 5 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
REVIT Files
.rfa icon REVIT File
3D Objects are not currently available for this product
