Features
- Metal handle and escutcheon plate.
- Metal swivel pull-out spray spout.
- Adjustable spray pattern with toggle button activation.
- Washerless 40mm ceramic disc valve cartridge.
- Braided flexible supply hoses with 3/8" compression connections.
- Metal mounting shank with brass fixation ring.
- Complete with two integral check valves.
- 2.2gpm/8.3L/min. maximum flow rate.
- Fitting can be mounted with or without escutcheon plate (escutcheon size 10-1/16"L x 2-1/2"W).
Technical Features
- Washerless (40 mm) ceramic disc valve cartridge
- Braided flexible supply hoses with 3/8" (10 mm) compression connectors
- Metal lever handle
- Can be mounted with or without supplied escutcheon
- Swivel spout
- Pull-out spray with adjustable spray pattern
- 2.2 gpm/8.3 L/min maximum flow
- Spout height: 8-7/16" (215 mm)
Nominal Dimensions: 10-1/2 in x 10-1/16 in x 10-9/16 in (267 mm x 256 mm x 268 mm)
