Quince

Quince® Single-Handle Pull-Out Dual-Spray Kitchen Faucet 1.5 gpm/5.7 L/min

4433100F15.075 DISCONTINUED   Substitution Available (4433100.075)
List Price: $0.00
Cal Green CEC Certified Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Metal handle and escutcheon plate
  • Metal swivel pull-out spray spout
  • Washerless 40mm ceramic disc valve cartridge
  • Braided flexible supply hoses with 3/8" compression connections
  • Metal mounting shank with brass fixation ring
  • Complete with two integral check valves
  • Adjustable spray pattern with toggle button activation
  • Fitting can be mounted with or without escutcheon plate (escutcheon size 10-1/16"L x 2-1/2"W)
  • 2.2gpm/8.3L/min. maximum flow rate
Technical Features
  • Washerless (40 mm) ceramic disc valve cartridge
  • Braided flexible supply hoses with 3/8" (10 mm) compression connectors
  • Metal lever handle
  • Can be mounted with or without supplied escutcheon
  • Swivel spout
  • Pull-out spray with adjustable spray pattern
  • 1.5 gpm/5.7 L/min maximum flow
  • Spout height: 8-7/16" (215 mm)
  • 2.2gpm/8.3L/min. maximum flow rate
Description
Net Weight
SKU
Color
List Price USD
Quince® Single-Handle Pull-Out Dual-Spray Kitchen Faucet 1.5 gpm/5.7 L/min
6 lb (2.9 kg)
4433100F15.075 *
0
4433100F15.002 *
0
4433100F15.224 *
0
Substitutions
Quince® Single-Handle Pull-Out Dual-Spray Kitchen Faucet 2.2 gpm/8.3 L/min
6 lb (2.7 kg)
4433100.075 *
0


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
Brand: American Standard
Cal Green: Yes
Category: Kitchen Faucets
CEC Certified: Yes
Color / Finish: Stainless Steel (075)
Collections: Quince
Escutcheon Internal Diameter: 1-5/16
Faucet Type: Mono block Pull Out
Fitting Connection Size Input: 9.52
Hose Length: 21
Fitting Material: Metal
Mount Type: Sink Mount
Number of Handles: 1
Fitting Number of Holes: 1
Spout Height: 6-7/16
Spout Type: Low Arc
Valve Material: Ceramic
Gallons Per Minute (min-max): 1.5 GPM
Input Connection Type: Compression
Height: 10-9/16
Width: 10-1/16
Residential or Commercial: Residential
Subcategory: Mono Block Pull Out Kitchen Faucets
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
REVIT Files
.rfa icon REVIT File
3D Objects are not currently available for this product
