Portsmouth® Single-Handle Pull-Out Dual-Spray Kitchen Faucet 1.5 gpm/5.7 L/min

Oil Rubbed Bronze 4285100F15.224 DISCONTINUED
List Price: $457.00
CEC Certified Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Ceramic Disc Valve Cartridge: Assures smooth, precise valve control and a lifetime of drip-free, maintenance-free performance
  • Memory Position Valving: Allows user to turn valve on and off at preferred temperature setting without readjusting handle position each time
  • Lead Free: Faucet contains 0.25 percent total lead content by weighted average
  • Integral Check Valves: Prevents back flow
  • Pull out Spray Spout: Switches water flow from a stream
  • 1.5 gpm/5.7 Lpm maximum flow
  • Metal lever handle
  • Can be mounted with or without supplied metal escutcheon
  • Braided flexible stainless steel supply hoses with 3/8" (10 mm) compression connections
Technical Features
  • Washerless ceramic disc valve cartridge
  • Metal lever handle
  • Can be mounted with or without supplied metal escutcheon
  • Braided flexible supply hoses with 3/8" (10 mm)compression connections
  • Swivel spout
  • Pull-out spray with adjustable spray pattern
  • 1.5 gpm/5.7 L/min maximum flow
  • Spout clearance: 6-5/16" (160 mm)
There are no additional components to display for this product
Download Specification Sheet
Brand: American Standard
Category: Kitchen Faucets
CEC Certified: Yes
Color / Finish: Oil Rubbed Bronze
Collections: Portsmouth
Faucet Type: Mono block Pull Out
Fitting Connection Size Input: 3/8
Mount Type: Sink Mount
Number of Handles: 1
Fitting Number of Holes: 1
Spout Height: 8-9/16
Valve Material: Ceramic
Gallons Per Minute (min-max): 1.5 GPM
Residential or Commercial: Residential
Subcategory: Mono Block Pull Out Kitchen Faucets
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
