Find Your Salesperson

Portsmouth

Portsmouth® Single-Handle Pull-Down Bar Faucet 1.5 gpm/5.7 L/min

Oil Rubbed Bronze 4285410F15.224 DISCONTINUED
List Price: $430.00
ADA Compliant CEC Certified Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Ceramic Disc Valve Cartridge: Assures smooth, precise valve control and a lifetime of drip-free, maintenance-free performance
  • Memory Position Valving: Allows user to turn valve on and off at preferred temperature setting without readjusting handle position each time
  • Lead Free: Faucet contains 0.25 percent total lead content by weighted average
  • Pull-down Spray: Single feature spray
  • Integral Check Valves: Prevents back flow
  • Brass swivel spout
  • Metal lever handle
  • Can be mounted with or without supplied metal escutcheon
  • Braided flexible stainless steel supply hoses with 3/8" (10 mm) compression connections
Technical Features
  • Washerless ceramic disc valve cartridge
  • Metal lever handle
  • Can be mounted with or without supplied metal escutcheon
  • Braided flexible supply hoses with 3/8" (10 mm) compression connections
  • Brass swivel spout
  • Pull-down spray
  • 2.2 gpm/8.3 L/min maximum flow
  • Spout height: 13-1/4" (337 mm)
  • Spout clearance: 9-1/4" (235 mm)
There are no additional components to display for this product
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Category: Kitchen Faucets
CEC Certified: Yes
Color / Finish: Oil Rubbed Bronze
Collections: Portsmouth
Faucet Type: Mono block Pull Down
Fitting Connection Size Input: 3/8
Fitting Material: Brass
Number of Handles: 1
Fitting Number of Holes: 1
Spout Height: 13-1/4
Spout Type: Stationary
Valve Material: Ceramic
Fixture or Fitting Material: Brass
Gallons Per Minute (min-max): 1.5 GPM
Input Connection Type: Compression
Height: 15-7/16
Width: 10
Pull Down Faucet: Yes
Residential or Commercial: Residential
Subcategory: Mono Block Pull Down Kitchen Faucets
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
