Features
- Cast brass swivel spout is 8-1/2" (216 mm) long with 5-1/8" (130 mm) clearance
- Metal Lever Handle with separate spray
- 2.2 gpm/8.3 Lpm maximum flow
- Ceramic disc valve cartridges (40 mm)
- Metal deck plate
Technical Features
- Ceramic disc valve cartridges (40 mm)
- Durable cast brass waterway with 1/2" (13 mm) male inlet shanks
- Cast brass swivel spout
- Spout length: 8-1/2" (216 mm)
- Spout height: 6-1/8" (155 mm)
- Spout clearance: 5-1/8" (130 mm)
- Metal deck plate and metal lever handle
- Color-matched side spray
- 2.2 gpm/8.3 L/min maximum flow
Nominal Dimensions: 10.2 in x 12.8 in x 7 in (259 mm x 325 mm x 178 mm)
Colony® Soft Single-Handle Kitchen Faucet 2.2 gpm/8.3 L/min With Side Spray
5 lb (2.3 kg)
Chrome (002)
262
Stainless Steel (075)
312
Colony® PRO Single-Handle Kitchen Faucet 1.5 gpm/5.7 L/min With Side Spray
4 lb (1.8 kg)
Chrome
208
Colony® Soft Single-Handle Kitchen Faucet 2.2 gpm/8.3 L/min With Side Spray
5 lb (2.3 kg)
Chrome (002)
262
Stainless Steel (075)
312
Colony® PRO Single-Handle Kitchen Faucet 1.5 gpm/5.7 L/min With Side Spray
4 lb (1.8 kg)
Chrome
208
Models marked with * are discontinued, but product may still be available while supplies last.
