Studio® S Single Hole Single-Handle Bathroom Faucet 1.2 gpm/ 4.5 L/min With Lever Handle

Contemporary, cosmopolitan design and soft geometry combine for the sleek Studio S Single-Handle Faucet.  The lever handle features an innovative design creating a flush look, eliminating gaps around the handle and comes with ceramic disc valves for drip free performance. The perfect addition for a modern bathroom, the edgy design of the Bathroom Faucet is constructed from brass making it durable for a lifetime of use.  Cast brass body Metal lever handles Braided flexible supply hoses with 3/8" (10 mm) compression connectors Metal Speed Connect® pop-up drain Hot Limit Safety Stop to reduce the risk of accidental scalding. Sustainability: CEC Listed; CALGreen Compliant

Features
  • Urban inspired design
  • Brass spout for a durable and long-lasting design
  • Ceramic disc valve cartridge for a lifetime of drip-free performance
  • WaterSense Certified - Water-saving maximum flow rate of 1.2 gallons per minute (1.2 gpm/4.5 L/min) without sacrificing performance
  • Metal Lever Handle
  • Metal Speed Connect® pop-up drain uses fewer parts and installs in less time
  • Integrated, color-coded flexible braided stainless steel supply hoses with 3/8" (10 mm) compression connectors
  • Integrated adjustable hot limit saftety stop to reduce the risk of scalding
  • Limited Lifetime Warrany on function and finish
Technical Features
  • Brass construction and washerless ceramic disc valve cartridge
  • Water-conserving 1.2 gpm/4.5 L/min pressure-compensating aerator
  • Braided flexible hoses with 3/8" (10 mm) compression connectors
  • Metal lever handle
  • Metal Speed Connect® pop-up drain
Nominal Dimensions: 5-1/2 in x 6-3/16 in x 7 in (140 mm x 157 mm x 178 mm)
Description
Net Weight
SKU
Color
List Price USD
Studio® S Single Hole Single-Handle Bathroom Faucet 1.2 gpm/ 4.5 L/min With Lever Handle
5 lb (2.2 kg)
Chrome (002)
0
Matte Black (243)
487
Brushed Nickel (295)
0
Substitutions
Studio® S Single Hole Single-Handle Bathroom Faucet 1.2 gpm/ 4.5 L/min With Lever Handle
4 lb (1.8 kg)
Chrome
384
Spare Parts
26MM Cartridge
0 lb (0.0 kg)
No Finish
13


Models marked with * are discontinued, but product may still be available while supplies last.
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Cal Green: Yes
Category: Bathroom Faucets
CEC Certified: Yes
Color / Finish: Chrome
Department of Energy Certified: Yes
Collections: Studio S
Drain Included: Yes
Drain Material: Brass
WaterSense: Yes
Faucet Type: Monoblock
Fitting Connection Size Input: 9.52
Handle Height: 7
Handle Material: Metal
Handle Type: Lever
Fitting Material: Brass
Mount Type: Deck Mount
Number of Handles: 1
Fitting Number of Holes: 1
Speed Connect: Yes
Spout Type: Mid Arc
Valve Material: Ceramic
Fixture or Fitting Material: Brass
Gallons Per Minute (min-max): 1.2 GPM
Handle Length: 5-1/16
Input Connection Type: Compression
Hardware Included: Yes
Height: 7
Height: 7
Length: 5-1/2
Width: 6-3/16
Residential or Commercial: Residential
Subcategory: Monoblock Bathroom Faucets
Valve Type: Volume Control Valves
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
