Atrio® New

Single Hole Single-Handle M-Size Bathroom Faucet 1.2 GPM

The Atrio Faucet Collection is the ultimate fusion of sophisticated design and precision performance you’ve come to expect from GROHE. Engineered to meet the demands of every bathroom Blueprint, Atrio offers extensive style options from wideset to wall mount lavatory faucets, each ensuring years of unequaled beauty and unrivaled satisfaction

Brushed Nickel 23831EN3 DISCONTINUED   Substitution Available (24351EN0)
List Price: $598.00
ADA Compliant Cal Green CEC Certified Water Efficient WaterSense
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Single hole installation
  • GROHE SilkMove 1.1" (28 mm) ceramic cartridge
  • Quick installation system
  • Swivel tubular C-spout with flow control
  • Stop limiter
  • Push-open 1 1/4" (32mm) waste set
  • Stainless steel flex lines
  • Flow rate: 1.2 gpm (4.5 l/min)
  • Energy Policy Act of 1992
  • NSF 61,ASME A112.18.1/CSA B125.1,US Federal and State material regulations,EPA WaterSense
Technical Features
  • GROHE SilkMove
  • GROHE StarLight
  • GROHE EcoJoy
  • 9 3/16" Faucet height
  • 4 15/16" Swivel spout reach
  • 6 7/16" Aerator height
  • Nylon braided flex hoses
  • CALGreen/CEC compliant
  • 1.2gpm (WaterSense)
Nominal Dimensions: 5-15/16 in x 5-1/2 in x 9-3/16 in (151 mm x 140 mm x 233 mm)
Description
Net Weight
SKU
Color
List Price USD
Single Hole Single-Handle M-Size Bathroom Faucet 1.2 GPM
6 lb (2.9 kg)
23831EN3 *
Brushed Nickel (GEN)
598
23831003 *
Chrome (G00)
460
Substitutions
Atrio Single Hole Single-Handle M-Size Bathroom Faucet, 1.2 GPM (4.5 L/min)
5 lb (2.2 kg)
24351EN0
Brushed Nickel
1597
Spare Parts
O-Ring (13.5 X 2.75mm)
0 lb (0.0 kg)
0128500M
Chrome
21
spacer
Fitting Ring
0 lb (0.0 kg)
07419000
Chrome
34
spacer
Plug
0 lb (0.1 kg)
45986000
Chrome
81
spacer
Cartridge
0 lb (0.1 kg)
46963000
Chrome
44
spacer
Watersaving Kit 1.0 GPM
0 lb (0.1 kg)
48186000
Chrome
61
spacer
Safety Ring
0 lb (0.0 kg)
4826600M
Chrome
13
spacer
Mounting Set
0 lb (0.1 kg)
48384000
Chrome
36
spacer
Flow Straightener Us
0 lb (0.0 kg)
48410000
No Finish
14
spacer
Pop-Up Waste Set (with overflow)
1 lb (0.6 kg)
65818000 *
Chrome
206


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: GROHE SPA
Cal Green: Yes
Category: Bathroom Faucets
CEC Certified: Yes
Color / Finish: Brushed Nickel
Department of Energy Certified: Yes
Collections: Atrio® New
WaterSense: Yes
Faucet Type: Monoblock
Fitting Connection Size Input: 9.52
Handle Type: Lever
Mount Type: Deck Mount
Number of Handles: 1
Fitting Number of Holes: 1
Spout Height: 6-7/16
Spout Type: Mid Arc
Gallons Per Minute (min-max): 1.2
Input Connection Type: Compression
Kitchen or Bathroom: Bath
Height: 9-3/16
Length: 5-15/16
Width: 5-1/2
Residential or Commercial: Residential
Subcategory: Monoblock Bathroom Faucets
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
2D CAD Files
.dwg icon 2D CAD File
.dxf icon 2D CAD File
3D CAD Files
.dxf icon 3D CAD File
REVIT Files
.rfa icon REVIT File
There are no videos currently available for this product
3D Objects are not currently available for this product
