Features
- Easy One-Person installation with an exclusive Speed Connect metal drain
- Cast brass underbody with “City Shanks” are strong and durable, providing a wobble-free installation
- Adjustable Hot Limit Safety Stop limits the amount of hot water allowed to mix with cold, to reduce the risk of accidental scalding
- Ceramic disc valve cartridge assures a lifetime of drip-free performance
- Lead Free
- ADA Compliant design is easy to use
- 1.2 gallons per minute (1.2 gpm/4.5 L/min.) maximum flow rate helps to save water
- Centerset faucet on 4” centers
- Washerless 40 mm ceramic disc valve cartridge with hot limit safety stop
Technical Features
- 40 mm ceramic disc valve cartridge with an adjustable Hot Limit Safety Stop
- Durable cast brass 1/2" (13 mm) male inlet shanks
- Metal body with color-matched underbody
- Water-conserving 1.2 gpm/4.5 L/min pressure-compensating aerator
- Metal lever handle
- Red/Blue index button
- Metal Speed Connect® pop-up drain
- Easy installation with an exclusive Speed Connect® drain
Nominal Dimensions: 6.3 in x 6 in x 4.7 in (160 mm x 152 mm x 119 mm)
Colony® Soft 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 L/min With Lever Handle
4 lb (1.7 kg)
Chrome (002)
191
Brushed Nickel (295)
261
Colony® PRO 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 L/min With Lever Handle
3 lb (1.4 kg)
Chrome
193
Colony® Soft 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 L/min With Lever Handle
4 lb (1.7 kg)
Chrome (002)
191
Brushed Nickel (295)
261
Colony® PRO 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 L/min With Lever Handle
3 lb (1.4 kg)
Chrome
193
Models marked with * are discontinued, but product may still be available while supplies last.
Didn't find the PDF or file you were looking for? Reach out to our team via our
Contact Form.
There are no design files currently available for this product
3D Objects are not currently available for this product
