Features
- Flowise Water Saving 3-Function Showerhead: Saves up to 40% in water usage. Max. 2.0gpm/7.6L/min. flow rate.
- Cast Brass Valve Body: Durable - Quality that will last a lifetime. Ideal material for prolonged contact with water.
- Ceramic Disc Valve Cartridge: Assures a lifetime of drip-free performance. Allows easy control over both water temperature and volume.
- Pressure Balancing Valve Cartridge: Maintains constant output temperature in response to changes in relative hot and cold supply pressure. Diaphragm system engineered to eliminate cross flow. Avoids failure due to mineral deposits - ideal for use in hard water.
- Back-to-Back Capability: Hot and cold can be reversed quickly and easily.
- Adjustable Hot Limit Safety Stop: Limits the amount of hot water allowed to mix with cold. Reduces the risk of accidental scalding.
- Exclusive Plaster Guard: Plaster guard is designed to protect valve during installation and serve as a mounting plate for thin-wall installations. Two piece design allows valve to be tested prior to trim installation.
- Wide Rough-in Range: From 1-5/8" to 3-1/4".
- Metal lever handle
Technical Features
- Flowise Water Saving 3-Function Showerhead: Saves up to 40% in water usage. Max. 2.0gpm/7.6L/min. flow rate.
- Cast Brass Valve Body: Durable - Quality that will last a lifetime. Ideal material for prolonged contact with water.
- Ceramic Disc Valve Cartridge: Assures a lifetime of drip-free performance. Allows easy control over both water temperature and volume.
- Pressure Balancing Valve Cartridge: Maintains constant output temperature in response to changes in relative hot and cold supply pressure. Diaphragm system engineered to eliminate cross flow. Avoids failure due to mineral deposits - ideal for use in hard water.
- Back-to-Back Capability: Hot and cold can be reversed quickly and easily.
- Adjustable Hot Limit Safety Stop: Limits the amount of hot water allowed to mix with cold. Reduces the risk of accidental scalding.
- Exclusive Plaster Guard: Plaster guard is designed to protect valve during installation and serve as a mounting plate for thin-wall installations. Two piece design allows valve to be tested prior to trim installation.
- Wide Rough-in Range: From 1-5/8" to 3-1/4".
- Metal lever handle
Nominal Dimensions: 10.3 in x 6.4 in x 9.1 in (262 mm x 163 mm x 231 mm)
There are no additional components to display for this product
Brand:
American Standard
Cal Green:
Yes
Category:
Bathroom Faucets
Color / Finish:
Oil Rubbed Bronze
Collections:
Quentin
WaterSense:
Yes
Faucet Type:
Bath Trim
Fitting Connection Size Input:
1/2
Handle Type:
Lever
Spout Type:
Tub
Gallons Per Minute (min-max):
2 GPM
Height:
9.1
Length:
10.3
Width:
6.4
Residential or Commercial:
Residential
Shower Diverter Type:
Lever
Number of Showerheads:
1
Number of Spray Settings:
3
Shower Trim Type:
Shower
Subcategory:
Bath Trim Bathroom Faucets
Warranty:
Limited Lifetime Warranty
