Features
- ACCESS 3 TYPES OF WATER: Pushbutton control delivers filtered and chilled water as you like it: still, medium or sparkling
- COLOR DISPLAY: Intuitive and easy to use featuring push and turn control
- KIT INCLUDES: Kitchen faucet, cooler, flexible connection hoses and filter head with flexible water hardness adjustment. Water hardness must be above 36 PPM for proper carbonation.
- MINIMUMUM SPACE REQUIRED: Under the sink area must be at least 23-5/8 in. W x 19-11/16 in. D x 16-15/16 in. H
- REQUIRED: GROHE Blue filter, CO2 tank and cleaning cartridge, sold separately, are required for installation
- WI-FI AND BLUETOOTH: Interface monitors functions via app, see Spec Sheet for details
- FILTERED SWIVEL FAUCET: Two separate inner water ways, one for filtered water options and another for non-filtered tap water dispensed by lever handle
- COOLING UNIT: 270-watt, 110 V AC requires ventilation holes in the bottom of the kitchen cabinet
Technical Features
- GROHE SilkMove
- GROHE LongLife finish
- 14 1/2" Faucet height
- 13 1/16" Aerator height
- 8 3/4" Faucet reach
- 150° Swivel radius
- Pull-out single spray
- 1.75 gpm (6.6 L/min)
- Push buttons for 3 types of filtered and chilled water: still, medium, and sparkling
- Separate inner water ways for filtered and non-filtered water,Flexible connection hoses,GROHE Blue Professional cooler delivers over 3 gallons of chilled water per hour,Color display with push and turn control,270 Watt cooling unit, 110V AC,Requires ventilation holes in the bottom of the kitchen cabinet,Includes filter head with flexible water hardness adjustment. Water hardness must be above 36 PPM for proper carbonation,GROHE Blue Filter, CO² tank and cleaning cartridge sold separately,ASSE 1022 compliant backflow preventer included,CALGreen compliant,Minimum space required under sink 23 5/8" W x 19 11/16" D x 16 15/16" H,Software set-up and monitoring of filter and CO² capacity via GROHE WaterSystem app*,Additional monitoring via GROHE Blue Professional Browser - Monitor possible with Bluetooth 4.0** and WiFi interface for wireless data communication,For Apple*** and Android devices, Bluetooth range (max. 32ft) varies depending on used materials and walls between transmitter and receiver,*WPA2 encrypted and password protected network, MAC address filters are not supported. iPhone with iOS 9.0 or higher / smartphone with Android 4.3 or higher. Mobile devices and GROHE WaterSystem app are not included in delivery and have to be ordered separately via an authorized Apple store/store/iTunes or Google Play store.,**The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by GROHE AG is under license. Other trademarks and trade names are those of their respective owners.,***Apple, the Apple logo, iPod, iPod Touch, iPhone and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries. Apple is not responsible for the function of this device or its compliance with safety and regulatory standards.
Nominal Dimensions: 17-3/4 in x 10-7/16 in x 15-3/4 in (451 mm x 265 mm x 400 mm)
GROHE Blue Single-Handle Pull-Out Kitchen Faucet Single Spray 1.75 GPM (6.6 L/min) with Chilled & Sparkling Water
49 lb (22.2 kg)
Supersteel (GDC)
6262
Chrome (G00)
4639
GROHE Blue Carbon Filter, S-Size
2 lb (0.8 kg)
No Finish
123
spacer
GROHE Blue Carbon Filter, L-Size
4 lb (1.6 kg)
No Finish
213
spacer
GROHE Blue Carbon Filter, M-Size
3 lb (1.1 kg)
No Finish
159
spacer
GROHE Blue Activated Carbon Filter
2 lb (0.7 kg)
No Finish
104
spacer
GROHE Blue Ultrasafe Filter
1 lb (0.6 kg)
No Finish
286
spacer
GROHE Blue Magnesium + Zinc Filter
3 lb (1.2 kg)
No Finish
202
spacer
GROHE Blue Cleaning Cartridge Adapter
0 lb (0.1 kg)
Chrome
104
spacer
GROHE Blue Cleaning Cartridge
1 lb (0.6 kg)
No Finish
164
Support Plate
0 lb (0.0 kg)
Chrome
22
spacer
Fitting Ring
0 lb (0.0 kg)
Chrome
34
spacer
GROHE Blue Carbon Filter, S-Size
2 lb (0.8 kg)
No Finish
123
spacer
GROHE Blue Glass Carafe
3 lb (1.2 kg)
No Finish
75
spacer
GROHE Blue Carbon Filter, L-Size
4 lb (1.6 kg)
No Finish
213
spacer
GROHE Blue Carbon Filter, M-Size
3 lb (1.1 kg)
No Finish
159
spacer
GROHE Blue Cleaning Cartridge GROHE Blue Cleaning Cartridge
1 lb (0.6 kg)
Chrome
75
spacer
GROHE Blue Activated Carbon Filter
2 lb (0.7 kg)
No Finish
104
spacer
GROHE Blue Magnesium Filter
2 lb (1.1 kg)
No Finish
106
spacer
GROHE Blue Cleaning Cartridge Adapter
0 lb (0.1 kg)
Chrome
104
spacer
Cartridge
0 lb (0.1 kg)
Chrome
158
spacer
Cap
0 lb (0.0 kg)
Chrome
24
Matte Black
33
Brushed Cool Sunrise
35
spacer
Operating Unit - Grohe Blue 2.0
0 lb (0.0 kg)
Supersteel
0
spacer
Quick Coupling 1.75 GPM (6.6 L/min)
0 lb (0.0 kg)
Chrome
41
spacer
Pressure Indicator/-Reducer
2 lb (0.9 kg)
Chrome
16
spacer
Mounting Set
0 lb (0.1 kg)
Chrome
36
spacer
GROHE Blue Filter Head
1 lb (0.3 kg)
Chrome
99
Grohe Blue Prof. Cooler
0 lb (0.0 kg)
Chrome
3376
spacer
Grohe Blue Extension Set
1 lb (0.4 kg)
Chrome
240
spacer
Lever
0 lb (0.2 kg)
Supersteel
117
spacer
Pull Out Spray
0 lb (0.1 kg)
Supersteel
164
GROHE Blue Single-Handle Pull-Out Kitchen Faucet Single Spray 1.75 GPM (6.6 L/min) with Chilled & Sparkling Water
49 lb (22.2 kg)
Supersteel (GDC)
6262
Chrome (G00)
4639
GROHE Blue Carbon Filter, S-Size
2 lb (0.8 kg)
No Finish
123
spacer
GROHE Blue Carbon Filter, L-Size
4 lb (1.6 kg)
No Finish
213
spacer
GROHE Blue Carbon Filter, M-Size
3 lb (1.1 kg)
No Finish
159
spacer
GROHE Blue Activated Carbon Filter
2 lb (0.7 kg)
No Finish
104
spacer
GROHE Blue Ultrasafe Filter
1 lb (0.6 kg)
No Finish
286
spacer
GROHE Blue Magnesium + Zinc Filter
3 lb (1.2 kg)
No Finish
202
spacer
GROHE Blue Cleaning Cartridge Adapter
0 lb (0.1 kg)
Chrome
104
spacer
GROHE Blue Cleaning Cartridge
1 lb (0.6 kg)
No Finish
164
Support Plate
0 lb (0.0 kg)
Chrome
22
spacer
Fitting Ring
0 lb (0.0 kg)
Chrome
34
spacer
GROHE Blue Carbon Filter, S-Size
2 lb (0.8 kg)
No Finish
123
spacer
GROHE Blue Glass Carafe
3 lb (1.2 kg)
No Finish
75
spacer
GROHE Blue Carbon Filter, L-Size
4 lb (1.6 kg)
No Finish
213
spacer
GROHE Blue Carbon Filter, M-Size
3 lb (1.1 kg)
No Finish
159
spacer
GROHE Blue Cleaning Cartridge GROHE Blue Cleaning Cartridge
1 lb (0.6 kg)
Chrome
75
spacer
GROHE Blue Activated Carbon Filter
2 lb (0.7 kg)
No Finish
104
spacer
GROHE Blue Magnesium Filter
2 lb (1.1 kg)
No Finish
106
spacer
GROHE Blue Cleaning Cartridge Adapter
0 lb (0.1 kg)
Chrome
104
spacer
Cartridge
0 lb (0.1 kg)
Chrome
158
spacer
Cap
0 lb (0.0 kg)
Chrome
24
Matte Black
33
Brushed Cool Sunrise
35
spacer
Operating Unit - Grohe Blue 2.0
0 lb (0.0 kg)
Supersteel
0
spacer
Quick Coupling 1.75 GPM (6.6 L/min)
0 lb (0.0 kg)
Chrome
41
spacer
Pressure Indicator/-Reducer
2 lb (0.9 kg)
Chrome
16
spacer
Mounting Set
0 lb (0.1 kg)
Chrome
36
spacer
GROHE Blue Filter Head
1 lb (0.3 kg)
Chrome
99
Grohe Blue Prof. Cooler
0 lb (0.0 kg)
Chrome
3376
spacer
Grohe Blue Extension Set
1 lb (0.4 kg)
Chrome
240
spacer
Lever
0 lb (0.2 kg)
Supersteel
117
spacer
Pull Out Spray
0 lb (0.1 kg)
Supersteel
164
Models marked with * are discontinued, but product may still be available while supplies last.
3D Objects are not currently available for this product
2D CAD File
2D CAD File
REVIT File
