Features
- Swivel spout
- Spout height 6" (152mm)
- Pull-out spray with adjustable spray pattern
- No visible button or toggle-simply pull down to switch from stream to spray
- Metal lever handle
- Can be mounted with or without supplied escutcheon
- 21" (508mm) braided flexible supply hoses with 3/8" compression connectors
Technical Features
- Metal lever handle
- Can be mounted with or without supplied escutcheon
- 20" (508 mm) braided flexible supply hoses with 3/8" (10 mm) compression connectors
- Swivel spout
- Spout height: 7-3/16" (183 mm)
- Spout clearance: 3-13/16" (97 mm)
- Pull-out spray with adjustable spray pattern
- No visible button or toggles — simply pull down to switch from stream to spray
- Washerless ceramic disc valve cartridge (47 mm)
Nominal Dimensions: 11.4 in x 10 in x 8.7 in (290 mm x 254 mm x 221 mm)
Colony® Soft Single-Handle Pull-Out Dual Spray Kitchen Faucet 2.2 gpm/8.3 L/min
5 lb (2.5 kg)
Stainless Steel (075)
370
Chrome (002)
286
0
Colony® PRO Single-Handle Pull-Out Dual Spray Kitchen Faucet 1.5 gpm/5.7 L/min
7 lb (3.4 kg)
Stainless Steel
419
Volume and Temperature Control\nPressure Balance Valve Cartridge
0 lb (0.1 kg)
No Finish
36
spacer
BUTTON & SET SCREW
0 lb (0.0 kg)
No Finish
9
spacer
Kitchen Faucet Deck Plate
1 lb (0.2 kg)
Stainless Steel
44
Stainless Steel
58
spacer
MOUNTING KIT
0 lb (0.1 kg)
No Finish
17
spacer
Internal Body And Seal
0 lb (0.0 kg)
No Finish
9
Colony® Soft Single-Handle Pull-Out Dual Spray Kitchen Faucet 2.2 gpm/8.3 L/min
5 lb (2.5 kg)
Stainless Steel (075)
370
Chrome (002)
286
0
Colony® PRO Single-Handle Pull-Out Dual Spray Kitchen Faucet 1.5 gpm/5.7 L/min
7 lb (3.4 kg)
Stainless Steel
419
Volume and Temperature Control\nPressure Balance Valve Cartridge
0 lb (0.1 kg)
No Finish
36
spacer
BUTTON & SET SCREW
0 lb (0.0 kg)
No Finish
9
spacer
Kitchen Faucet Deck Plate
1 lb (0.2 kg)
Stainless Steel
44
Stainless Steel
58
spacer
MOUNTING KIT
0 lb (0.1 kg)
No Finish
17
spacer
Internal Body And Seal
0 lb (0.0 kg)
No Finish
9
Models marked with * are discontinued, but product may still be available while supplies last.
