Lineare™

Single Hole Single-Handle XS-Size Bathroom Faucet, 1.2 GPM (4.5 L/min)

Clean, unpretentious lines define the GROHE Lineare Bathroom Faucet. This contemporary faucet is equipped with exclusive GROHE technology including GROHE SilkMove for smooth, precise handle operation, and GROHE EcoJoy to reduce water usage without sacrificing performance. Lineare is engineered with the precision and craftsmanship that have made GROHE the choice for discerning homeowners.

Chrome 2382400A DISCONTINUED
List Price: $491.00
ADA Compliant Cal Green CEC Certified Enjoy More Rewards LIXIL Select WaterSense
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • GROHE QuickFix Plus requires minimal threading for fast, easy installation
  • GROHE AquaGuide is an adjustable aerator that directs angle of water flow from 20° to 40°
  • Quality solid brass construction with metal lever handle
  • 23 1/2" nylon braided flex hoses
  • WaterSense certified, uses 1.2gpm for water conservation
Technical Features
  • GROHE SilkMove
  • GROHE LongLife finish
  • GROHE EcoJoy
  • GROHE QuickFix Plus installation
  • GROHE AquaGuide adjustable aerator 20°-40°
  • 7 3/8" Faucet height (open position)
  • 6 1/8" Faucet height (closed position)
  • 4 3/16" Spout reach
  • 3 3/4" Aerator height
  • Solid brass construction with metal lever,23 1/2" Nylon brained flex hoses,CALGreen/CEC compliant,1.2gpm (WaterSense)
Nominal Dimensions: 6 in x 1-3/4 in x 6-1/8 in (152 mm x 44 mm x 156 mm)
Description
Net Weight
SKU
Color
List Price USD
Single Hole Single-Handle XS-Size Bathroom Faucet, 1.2 GPM (4.5 L/min)
3 lb (1.4 kg)
2382400A
Chrome (G00)
491
23824243A
Matte Black (243)
664
23824A0A
Hard Graphite (GA0)
713
23824ENA
Brushed Nickel (GEN)
664
23824GNA
Brushed Cool Sunrise (GGN)
713
Spare Parts
Fitting Ring
0 lb (0.0 kg)
07419000
Chrome
34
spacer
Mounting Wrench
1 lb (0.3 kg)
19017000
Chrome
21
spacer
Cartridge
0 lb (0.1 kg)
46580000
Chrome
158
spacer
Cap
0 lb (0.0 kg)
46581000
Chrome
24
spacer
Shank Mounting Kit
0 lb (0.1 kg)
46645000
Chrome
34
spacer
Lift Rod
0 lb (0.2 kg)
46739000
Chrome
61
spacer
Lever
1 lb (0.2 kg)
46980000
Chrome
80
spacer
Flow Straightener Adjust
0 lb (0.1 kg)
48300000
Chrome
12
spacer
Plug
0 lb (0.1 kg)
48331000
Chrome
15
spacer
Actuating Rod
0 lb (0.1 kg)
48332000
Chrome
15
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: GROHE
Cal Green: Yes
Category: Bathroom Faucets
CEC Certified: Yes
Color / Finish: Chrome
Department of Energy Certified: Yes
Collections: Lineare™
Drain Included: Yes
Drain Material: Metal
WaterSense: Yes
Faucet Type: Monoblock
Fitting Connection Size Input: 9.52
Handle Height: 6-1/8
Handle Material: Metal
Handle Type: Lever
Hose Length: 21.062992125984252
Fitting Material: Metal
Mount Type: Deck Mount
Number of Handles: 1
Fitting Number of Holes: 1
Spout Height: 3-3/4
Spout Type: Low Arc
Fixture or Fitting Material: Metal
Gallons Per Minute (min-max): 1.2
Input Connection Type: Compression
Kitchen or Bathroom: Bath
LIXIL Select: Yes
Height: 6-1/8
Length: 6
Width: 1-3/4
Residential or Commercial: Residential
Subcategory: Monoblock Bathroom Faucets
Warranty: Limited Lifetime Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
There are no videos currently available for this product
3D Objects are not currently available for this product
