Features
- Includes one-piece cartridge to simplify installation and maintenance
- Double ceramic pressure balance cartridge features a ceramic disc mixing valve and a ceramic balancing spool
- Ceramic disc mixing valve ensures a lifetime of drip-free performance and smooth handle operation
- Ceramic balancing spool maintains a constant water temperature
- Integrated check valves are engineered to eliminate cross flow
- Adjustable hot limit safety stop reduces the risk of accidental scalding
- Offers a wide comfort zone to fine tune to the desired temperature
- For use with GrohSafe 3.0 rough-in valves, sold separately
Technical Features
- GROHE StarLight
- GROHE SilkMove
- Metal handle
- Metal trim plate with GROHE QuickFix
- Includes pressure balance cartridge with double ceramic technology
- 5.2gpm (bottom) and 3.0gpm (top port) at 45 psi (19 L/min)
- Requires GrohSafe 3.0 Rough-in Valve (35 110, 35 111, 35 112, 35 113, 35 114, 35 115, or 35 116) (sold separately)
Nominal Dimensions: 6-5/6 in x 3-1/2 in x 7 in (174 mm x 89 mm x 178 mm)
Pressure Balance Valve Trim with Cartridge
2 lb (0.9 kg)
Chrome (G00)
216
Pressure Balance Rough-In Valve 1/2" Universal
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" PEX Crimp (ASTM F1960) Inlets
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" PEX Cold Expansion (ASTM F1960) Inlets
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" Stub-out Inlets/Outlets
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" CPVC Inlets
2 lb (0.9 kg)
No Finish
138
spacer
Pressure Balance Rough-In Valve 1/2" PEX Crimp (ASTM F1807) Elbow Inlets
2 lb (0.9 kg)
No Finish
152
spacer
Pressure Balance Rough-In Valve 1/2" PEX Cold Expansion (ASTM F1960) Elbow Inlets
2 lb (0.9 kg)
No Finish
138
GrohSafe 3.0 Cartridge With Removal Ring
0 lb (0.1 kg)
Chrome
90
Pressure Balance Valve Trim with Cartridge
2 lb (0.9 kg)
Chrome (G00)
216
Pressure Balance Rough-In Valve 1/2" Universal
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" PEX Crimp (ASTM F1960) Inlets
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" PEX Cold Expansion (ASTM F1960) Inlets
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" Stub-out Inlets/Outlets
2 lb (0.8 kg)
No Finish
113
spacer
Pressure Balance Rough-In Valve 1/2" CPVC Inlets
2 lb (0.9 kg)
No Finish
138
spacer
Pressure Balance Rough-In Valve 1/2" PEX Crimp (ASTM F1807) Elbow Inlets
2 lb (0.9 kg)
No Finish
152
spacer
Pressure Balance Rough-In Valve 1/2" PEX Cold Expansion (ASTM F1960) Elbow Inlets
2 lb (0.9 kg)
No Finish
138
GrohSafe 3.0 Cartridge With Removal Ring
0 lb (0.1 kg)
Chrome
90
Models marked with * are discontinued, but product may still be available while supplies last.
